Radiation Heat Surface Boiler Wall Unit Prevent Coking Arranged Convection Tubes

Boiler Accessory Membrane Water Wall Panel For Hot Water Heaters water wall in boiler

Boiler Accessory Membrane Water Wall Panel Specification

1. Membrane water wall is main radiation heat surface, arranged inside the boiler chamber and proceeds the heat exchange directly with the high temperature flame.

2. The convection tubes are the convection heat surface of the boiler, arranged between the boiler chamber outlet and the end heat surface and proceed the heat exchange directly with the high temperature fume.

Introduction

1. Membrane water wall that are made of tubes welded together with or without a strip of metal in between.

2. These walls form the enclosure of the coal combustion chamber.

3. Membrane water wall are also referred to as the evaporator section; they contain water mostly in liquid form which gradually evaporates as it rises in the steam boiler

Advantages

1. Thermal efficiency saving membrane water wall with non-destructive equipment test are membrane walls that are made of tubes welded together with or without a strip of metal in between.

2. These walls form the enclosure of the coal combustion chamber. Water wall tubes are also referred to as the evaporator section.

3. They contain water mostly in liquid form which gradually evaporates as it rises in the boiler.

Workshop Display

water wall tubes

boiler wall unit

Radiation Heat Surface Boiler Wall Unit Prevent Coking Arranged Convection Tubes Images
